StarTech.com 3ft [1m] DB9 to 3.5mm Serial Cable for Serial Device Configuration, RS232 DB9 Male to 3.5mm Cable Used for Calibrating Projectors, Digital Signage, TVs via Audio Jack

Name: StarTech.com 3ft [1m] DB9 to 3.5mm Serial Cable for Serial Device Configuration, RS232 DB9 Male to 3.5mm Cable Used for Calibrating Projectors, Digital Signage, TVs via Audio Jack
Brand: StarTech.com
SKU: B47041680
Price: 13.62 EUR
Availability: InStock

MPN: 9M351M-RS232-CABLE

Quick Code: B47041680

(1M DB9 TO 3.5MM SERIAL CABLE - - RS232 MALE TO 3.5MM SERIAL CABLE)

🔍

StarTech.com 3ft [1m] DB9 to 3.5mm Serial Cable for Serial Device Configuration, RS232 DB9 Male to 3.5mm Cable Used for Calibrating Projectors, Digital Signage, TVs via Audio Jack

Note: Image accuracy is not guaranteed. Please do not rely solely on the image for your purchase.

📹 View Product Demo

€13.62

€16.48 inc. VAT

All products on this website are available duty-free in the EU
Overseas Customers with EU-VAT number do not pay VAT. - Verify it here

Quick Code: B47041680

MPN: 9M351M-RS232-CABLE

Manufacturer: StarTech.com

EAN Code: 0065030893565

💰 Get Cash Back if paying by Debit Card or Bank Transfer!

Learn more

Are you a System Builder? Use our online PC Designer Tool!

Choose the right Connector

Use our Connector Wizard

📧 Request More Info

Have questions? Need a quote?

📬 Notify me when price drops

Overview Detailed Specs Options and Warranties

NOTE: The information below is provided for your convenience only and we cannot guarantee its accuracy. If necessary, please verify with us before purchasing.

StarTech.com 3ft (1m) DB9 to 3.5mm Serial Cable for Serial Device Configuration, RS232 DB9 Male to 3.5mm Cable Used for Calibrating Projectors, Digital Signage, TVs via Audio JackStarTech.com 3ft (1m) DB9 to 3.5mm Serial Cable for Serial Device Configuration, RS232 DB9 Male to 3.5mm Cable for Calibrating Projectors, Digital Signage, TVs via Audio Jack (9M351M-RS232-CABLE)

Connect a DB9 enabled control unit to a 3.5mm enabled device for RS-232 based control

This serial cable features male DB-9 and 3.5mm connectors. It enables remote serial RS232 calibration of TVs, projectors, and digital signage devices that feature a 3.5mm audio jack.

High Quality Construction

The aluminum-mylar cable shielding and metal shell connectors mitigate EMI. The molded PVC connectors with strain reliefs and PVC cable jacket prevent damage caused by strain and/or abrasion.

Secure the DB-9 connector by tightening the integrated thumbscrews. These connector screw locks prevent accidental disconnection which could lead to data loss/corruption.

DB9 Serial to 3.5mm Pinout

DB9 Pin 3 to 3.5mm Tip

DB9 Pin 2 to 3.5mm Ring

DB9 Pin 5 to 3.5mm Sleeve

This product is backed for life, including free lifetime 24/5 multi-lingual technical assistance.
