Moxa NPort 5430 serial server RS-422/485
MPN: NPort 5430
Quick Code: B44376999
(Serial Server Rs-422/485 - Warranty: 12M)
Note: Image accuracy is not guaranteed. Please do not rely solely on the image for your purchase.
€1145.46
€1386.01 inc. VAT
All products on this website are available duty-free in the EU
Overseas Customers with EU-VAT number do not pay VAT. - Verify it here
Overseas Customers with EU-VAT number do not pay VAT. - Verify it here
PLEASE NOTE: there is a 17 day lead time on dispatch for this item.
Quick Code:
B44376999
MPN:
NPort 5430
Manufacturer:
Moxa
EAN Code:
5715063274132
💰 Get €8.32 Cash Back if paying by Debit Card or Bank Transfer!
NOTE: The information below is provided for your convenience only and we cannot guarantee its accuracy. If necessary, please verify with us before purchasing.
Moxa NPort 5430 serial server RS-422/4854-port RS-232/422/485 serial device servers
- 10/100M auto-sensing Ethernet- 4 serial ports, with support for RS-232, RS-422, and RS-485
- Built-in 15 KV ESD surge protection for all serial signals
- Versatile socket operation modes, including TCP Server, TCP Client, UDP, and Real COM
- Choice of configuration methods: Web console, Telnet console, and Windows utility
- SNMP MIB-II for network management
- 2 KV isolation protection for NPort 5430I/5450I/5450I-T
- 40 to 75°C operating temperature range (T model)
- Supports Moxa's MXview industrial network management software via the MXview Plug-in
Network Readiness for up to Four Serial Devices
NPort 5400 series device servers can conveniently and transparently connect up to four serial devices to an Ethernet network, allowing you to network your existing serial devices with only basic configuration. Data transmission between the serial and Ethernet interfaces is bi-directional. By using NPort device servers, you not only protect your current hardware investment, but also allow for future network expansion. You can both centralize the management of your serial devices, and distribute management hosts over the network.
Independent Operation Mode for Each Serial Port
NPort 5400 series device servers can be used to connect different devices for remote data polling or event handling over a TCP/IP network. Each serial port on the NPort 5400 series operates independently to provide maximum versatility. For example, port 1 can operate in Driver mode, port 2 in TCP Server mode, and ports 3 and 4 in TCP Client mode.
User-friendly LCD Panel for Easy Installation
An LCD panel is built into the NPort 5400’s top panel, with four buttons for inputting data, configuration, and selecting the operation mode. The LCD panel displays the server name, serial number, and IP address, and can be used to enter or modify parameters such as IP address, netmask, and gateway. (The LCD panel is not available on wide temperature models.)
Dual DC Power Inputs
NPort 5400 device servers support dual power sources by providing both a DC terminal block input and a DC power jack input. Providing two types of power input gives users greater flexibility for use with different applications.
Adjustable Termination and Pull High/Low Resistors
The NPort 5400 series provides adjustable termination and pull high/low resistors for RS-485 applications. In some critical environments, termination resistors may be needed to prevent the reflection of serial signals, and the pull high/low resistors may need adjusting to maintain the integrity of the electrical signal. Since no set of resistor values is universally compatible with all environments, the NPort® 5400 has four sets of DIP switches on the bottom panel to set the termination and pull high/low resistor values.
