METZ CONNECT 1401906113KE wire connector RJ-45 Grey
MPN: 1401906113KE
Quick Code: B51291277
(Wire Connector Rj-45 Grey - Warranty: 12M)
Note: Image accuracy is not guaranteed. Please do not rely solely on the image for your purchase.
€86.65
€104.85 inc. VAT
All products on this website are available duty-free in the EU
Overseas Customers with EU-VAT number do not pay VAT. - Verify it here
Overseas Customers with EU-VAT number do not pay VAT. - Verify it here
PLEASE NOTE: there is a 17 day lead time on dispatch for this item.
Quick Code:
B51291277
MPN:
1401906113KE
Manufacturer:
Metz
EAN Code:
💰 Get €0.63 Cash Back if paying by Debit Card or Bank Transfer!
NOTE: The information below is provided for your convenience only and we cannot guarantee its accuracy. If necessary, please verify with us before purchasing.
METZ CONNECT 1401906113KE wire connector RJ-45 GreyE-DAT Industry terminal rail TS35 + RJ45 field jack insert Cat.6 Class EA
- termination unit for mounting on TH35 rails to DIN EN 60715 in electrical distribution panels for home and industrial installations- equipped with E-DAT Industry RJ45 field jack insert
- vertical plugging direction, 90° to rail
- compliance with class EA to ISO/IEC 11801 Ed.2.2:2011-06, DIN EN 50173-1:2011-09
- suitable for 10 GBit Ethernet (IEEE 802.3an), Remote Powering (PoE, PoE plus and UPoE) and HDBaseT
- easy to install connection of 2 to 4 pair data lines AWG 24/1 - 22/1 and stranded wires with 7 copper conductors AWG 26/7 to BTR 8-fold insulation displacement connectors (IDC)
- width of 1HP allows mounting up to 12 units in a standard electrical distribution panel
- when mounted as a device of protection class I, the equipotential bonding is realized directly over the top hat rail by means of a switchable integrated equipotential spring. This has to be connected to the equipotential bonding of the building by means of a bonding terminal
- variants: pin assignment to T568A, T568B or PROFINET
